Tube Laser Cutting

Dimar Manufacturing’s BLM LT7 tube laser cuts one-of-a-kind items & prototypes to high volume manufacturing. The State-of-the-Art laser tube cutter reduces lead, welding and manufacturing times.

Benefits and Abilities of Tube Laser Cutting

• Bevel cutting for contouring, weld joint beveling and countersinks
• Reduces lead times and manufacturing costs
• Eliminates manual operations such as drilling, deburring, and shaping; these are combined into a single high-speed operation
• Eliminates tolerance stacking
• Infinite variations of cut geometry and configurations
• Self-locating joints
• Slot and tab construction; self-fixturing weld components
• Laser marking for labeling components

Capacities of Laser Tube Cutting Machine

• Bevel Cutting up to 45°
• Round Tube OD: .472” to 6.0”
• Square Tube: .472” to 6.0×6.0”
• Raw Stock Length: 28.2 ft
• Bundle Weight: 11,023 lbs
• Max Weight Per Linear Foot: 15.5 lbs/ft
• Max Weight Per Tube: 330.69 lbs

Tube, Pipe, Angle, Box, and Channel Materials:

• Carbon Steel
• Stainless Steel
• Aluminum
• Copper
• Bronze
• Brass
• Other Alloys
